總體參數

相機

對視場角                                                              83°

有效像素                                                             26MP

焦距                                                                    16mm

系統參數

精度                                                                    ≤10cm@110m

重量                                                                    1070g

工作溫度                                                             -20℃ ~ +55℃

尺寸                                                                   13.8cm×9.1cm×9.4cm

容量                                                                    64GB，最大支持128GB TF卡

激光單元

測程                                                                   230m@20%反射率，最大測程450m

測距精度                                                            ±2cm

激光類型                                                            905nm Class1 (IEC 60825-1:2014)

線數                                                                   等效64線

水平視場角                                                         70°

垂直視場角                                                         70°/4.5°

點頻                                                                   72萬點/秒（三次回波）

POS單元

更新頻率                                                            200Hz

Pitch/Roll 精度                                                    0.025°

航向精度                                                             0.080°

位置精度                                                            ≤0.05m

預處理軟件

POS（軌跡）軟件                                             Shuttle

點云軟件                                                            gAirHawk 5.0

測繪

飛行高度                                                       50m                           70m                   110m

精度                                                            ≤5cm                         ≤7cm                  ≤10cm

單個飛行操作（km2）                                 0.88                          1.28                    1.92
